1. The ultrasonic adopts a generator with an efficiency of up to 95%, and the power is adjustable from 0 to 100%; Using high-frequency ultrasonic frequencies such as 40KHz, 68KHz, and 80kHz;

2、高壓噴淋可有效解決后工序純水純度問題，有效降低純水消耗；

2. High pressure spraying can effectively solve the purity problem of pure water in subsequent processes, effectively reducing pure water consumption;

3、獨特的慢拉脫水，循環熱風干燥方式，安全環保；

3. Unique slow pull dehydration and circulating hot air drying method, safe and environmentally friendly;

4、多槽超聲波清洗工藝確保清洗效果；

4. Multi slot ultrasonic cleaning process ensures cleaning effect;

5、高度標準化：技術熟練、經驗豐富；

5. Highly standardized: skilled and experienced;

6、使用范圍：適用于各種光學產品的清洗，如液晶基板元器件、TFT、液晶玻璃；

6. Scope of use: Suitable for cleaning various optical products, such as LCD substrate components, TFT, and LCD glass;

7、清潔：多通道設計能有效解決產品污垢；

7. Cleaning: Multi channel design can effectively solve product dirt;

8、傳動系統：全自動多臂自動升降，采用全鋁機械結構，運行平穩，整體結構堅固，維修方便，技術成熟；

8. Transmission system: fully automatic multi arm automatic lifting and lowering, using an all aluminum mechanical structure, stable operation, solid overall structure, convenient maintenance, and mature technology;

9、采用優質電機，可有效控制機器各傳動部分的速度，并采用定位（專用電機+傳感器），確保清洗藍準確落入槽內，各工位清洗時間可調。

9. Using high-quality motors, the speed of each transmission part of the machine can be effectively controlled, and positioning (dedicated motor+sensor) is used to ensure that the cleaning blue accurately falls into the slot, and the cleaning time of each workstation can be adjusted.

液晶玻璃光學超聲波清洗機簡單故障排除：

Simple troubleshooting of LCD glass optical ultrasonic cleaning machine:

1、電源開關無法啟動：檢查主繼電器是否損壞；

1. The power switch cannot be started: check if the main relay is damaged;

2、油箱加熱故障；檢查油箱的加熱元件是否完好；

2. Fuel tank heating failure; Check if the heating element of the fuel tank is intact;

3、超聲波不工作：檢查超聲波電源元件是否損壞，換能器是否短路；

3. Ultrasonic does not work: Check if the ultrasonic power supply components are damaged and if the transducer is short circuited;

4、超聲波衰減：如果換能器受到濕氣、導電灰塵污染和強烈沖擊、漏電的影響，短路、擊穿、擦痕甚至脫落，導致超聲波衰減；

4. Ultrasonic attenuation: If the transducer is affected by moisture, conductive dust pollution, strong impact, leakage, short circuit, breakdown, scratches, or even detachment, resulting in ultrasonic attenuation;

5、如果換能器或超聲波發生器損壞，應立即停止使用，并及時維修。

5. If the transducer or ultrasonic generator is damaged, it should be stopped immediately and repaired in a timely manner.
